Solid Tyres

Tyre Dimensions - in inches.

 Load Capacity in Kg's

  LIP TYRES can be made available on request


CODE# Tyre Size Rim Tyre Dimension Load Capacity
Max Width OD

Load Wheel

  10 Kmph

Steer Wheel

16 Kmph

EG 1135275 3.504  2.75  3.55 9.64 - -
EG 1640250 4.008 2.50C 4.50 15.74 - 637
EG 1640275 4.008 2.75 4.50 15.74 - 700
EG1640300 4.008 3.00D 4.50 15.74 - 730
EG1640325 4.008 3.25A 4.50 15.74 - 828

EG 1640375

4.008

3.75 I-55,70

4.50 15.74 - 955
EG 1640300 5.008 3.00D 4.92 17.68 - 877
EG 1850325 5.008 3.25A 4.92 17.68 - 952
EG 1850375 5.008 3.75 1-55,70 4.92 17.68 - 1098
EG 1850450 5.008 4.50 7.00 18.00 - 1318
EG 1545325 154 1/2- 8 3.25 4.50 15.00 - 800
EG 1660433 166- 8 4.33R 6.00 16.00 1270 975
EG 1870433 187- 8 4.33R 6.25 18.00 2145 1650
EG 1890700 189 - 8 7.00 9.00 18.00 - -
EG 2160400 6.009 4.00E 6.14 20.25 1885 1390
EG 2180600 218 - 9 6.00E 7.57 21.25 2755 2032
EG 2365500 6.5010 5.00F 6.80 22.80 2340 1800
EG 2365550 6.5010 5.50F 6.80 22.80 2340 1800
EG 2575550 7.5010 5.00F 7.28 24.92 3070 2360
EG 2575550 7.5010 5.50F 7.28 24.92 3070 2360
EG2180650 218-10 6.50 8.30 21.22 - -
EG2390650 239-10 6.50F 9.00 23.00 3160 2430
EG 2670500 7.0012 5.00S 6.97 25.39 2920 2182
EG 2710800 2710 - 12 8.00S 9.92 25.50 3900 3000
EG 2970500 7.0015 5.50 7.48 27.28 3545 2597
EG 2670600 7.0015 6.00 6.97 27.28 3545 2597
EG 3075550 7.5015 - 30 5.50 7.48 27.28 3545 2597
EG 3075600 7.5015 - 30 6.00 7.48 27.28 3545 2597
EG 3075650 7.5015 - 30 6.50 7.48 27.28 3545 2597
EG 3275550 7.5015-32 5.50 8.40 30.70 4000 3000
EG 3275650 7.5015-32 6.50 8.40 30.70 4000 3000
EG 28815700  8.1515(289-15) 7.00 8.80 27.32 3445 2650
EG 32825550  8.1515-32 5.50 8.50 30.70 4000 3000
EG 32825650  8.1515-32 6.50 8.50 30.70 4000 3000
EG 33825550  8.2515-33 5.50 8.45 31.89 4750 3650
EG 33825650  8.2515-33 6.50 8.45 31.89 4750 3650
EG 29250700  25015 7.00 9.45 28.74 4362 3175
EG 29250750  25015 7.50 9.45 28.74 4362 3157
EG 32300800  30015 8.00 10.55 32.08 5735 4333
EG 28125975  2812.5 - 15 9.75 13.00 28.00 5034 4082
EG 32121975  3212.1 - 15 9.75 12.32 32.00 7143 5174
EG 30650550  6.5016 5.50 7.17 29.84 2910 2107
EG 3175550 7.5016 5.50 8.07 31.10 3908 2831
EG 3175600 7.5016 6.00 8.07 31.10 3908 2831
EG 3280550 8.0016 5.50 8.34 31.89 4000 3000
EG 34750600 7.5020 6.00 7.70 34.10 3840 3200
EG 38825700 8.2520 7.00 9.40 38.40 4400 2675
EG 3890650 9.0020 6.50 8.90 39.60 5340 4550
EG 3890700 9.0020 7.00 8.90 39.60 5340 4550
EG 3890750 9.0020 7.50 8.90 39.60 5340 4550
EG 4010750 10.0020-40 7.50 8.90 39.60 5340 4550
EG 401080 10.0020-40 8.00 8.90 39.60 5340 4550
EG 4110650 10.0020 6.50 11.00 41.00 5840 4865
EG 4110750 10.0020 7.50 11.00 41.00 5840 4865
EG 4110800 10.0020 8.00 11.00 41.00 5840 4865
EG 4212800 12.0020-42 8.00 11.00 41.00 5840 4865
EG 4312800 12.0020-43 8.00 11.70 43.20 7500 6113
EG 4312850 12.0020-43 8.50 11.70 43.20 7500 6113

SOLID TYRES
Size : 23 6.50 10/5.50
23    - Normal O/D
6.50 - Normal S/W
10    - Normal I/W
5.50 - Rim width
All Measurements - in inches
O/D   - Outer Diameter
S/W  - Section (Max) Width
I/D    - Inner Diameter
